| Type |
Rail mounted |
| Input |
Thermocouple: B, E, J, K, N, R, S and T |
| Type of transmitter |
Digital |
| Output |
4-20 mA |
| Measuring range |
Type J: -210…+1200 °C / -346…+2192 °F
Type K, N: -270…+1300 °C / -454…+2372 °F
Type R, S: -50…+1750 °C / -58…+3182 °F
Type B, E, T: See data sheet |
| Sensor error |
NAMUR NE43 |
| Adjustments – Zero point |
Any value within range limits |
| Adjustments – Minimum span |
20 °C / 36 °F |
| Ambient temperature |
–40…+85 °C / -40…+185 °F |
| Humidity |
0…98% RH (non-condensing) |
| Vibration |
IEC 60068-2-6,5 g |
| EMC |
EN 61326-1 and EN 61326-2-3 |
| Isolation |
Unisolated |
| Power supply |
6…32 VDC |
| Long-term stability |
Max. drift ±0,05 % of span/year |
| Typical accuracy |
Type E, J, K, N: ±1 K or ±0,2 % of span
Type B, R, S, T: ±2 K or ±0,2 % of span |
| Adjustable filtering level |
0,4 to 26 s |
| Wireless communication |
NFCTM |
